Peanut/groudnut combine harvester
| Specification | Type No. | 4HZJ-2500 | ||
| Structural style | self-propelled wheel type | |||
| Function | picking, crash and collect the straw | |||
| Size ( L, W, H ) | 6900*2900*3400 mm | |||
| Net weight | 5250kg | |||
| Gear box | mechanical | |||
| Engine brand | Changchai | |||
| Engine power | 120/130/140 hp | |||
| Cutting width | 2600 mm | |||
| Work efficiency | 0.3-0.7 hectare/hour | |||
| Total loss rate | ≤ 3.5% | |||
| Broken rate | ≤ 2.0 % | |||
| Impurity rate | ≤ 5.0 % | |||
| Stem recovery rate | ≥ 93 % | |||
| Unloading way | mechanical unloading | |||
| Fruit unloading height | 2350 mm | |||
| Grass unloading height | 2130 mm | |||
| Fruit tank volume | 2.5 m³ | |||
| Grass box volume | 4.5 m³ | |||
| Type of drive | 2 wheels drive | |||
| Transportation and Package | 1 set in a 40′HC (dis-assembled ) | |||
Product Features:
The machine is mainly used for peanut direct harvesting or drying harvesting after peanuts unearthed.Completing gathering, picking out, fruit vine separating and into the tank respectively at same time.
The picker uses a double track and runs smoothly.
The picking device adopts the circulation mode, and the
efficiency of picking is higher.
Clods cleaning adapts airflow pattern to prevent clogging and reduce the rate of broken peanut fruit.
Picking delivery method can be used when wet and dry peanut.
Using centrifugal fan to send grass, has good fruit grass separation effect and cleaner forage.
Removing dust downward, reduce air dust, extend the life of the
machine.
The machine has good performance, compact structure, easy operation, safe and reliable.The machine adapts to all the land that machine can handle.
